Programmable Logic Controller (PLC)

quick overview :

Programmable Logic Controller (PLC)

Make : ATICO

Country of Origin : INDIA

Technical Details:

Item : Programmable Logic Controller (PLC)

Construction : Modular and Expandable Mechanical Design, Suitable for panel or training setup
Portable and easy to install.

PLC Controller : Industrial Modular PLC System

Minimum I/O :

• DI ≥ 14, DO ≥ 10

• AI ≥ 2, AO ≥ 1

Power Supply : Input : 220–240 VAC, 50 Hz, Single Phase

Power Output : 24V DC, min. 2A; Includes Protection (Fuse / Over Current) and Power Indication

Communication : min. 1 x Industrial Ethernet Port; Supports IEC 61131-3 Programming Standard

Network Switch : min. 6 x RJ45 Ports; 10/100 Mbps, unmanaged Industrial grade

Simulation Module : min. 8 Channels; Support momentary and maintained switches for programming and testing

I/O Modules :

• Digital Input Module : min. 16 Channels; Opto-Isolation and Protection.

• Digital Output Module : min. 16 Channels

• Analog Module : min. 4 AI / 4 AO

• Signal Range : 0–10 V / 4–20 mA (or equivalent)

Communication Interface : Support RS-485 / Modbus / Ethernet-based communication; Allows external device integration. Include emergency stop (E-stop) interface capability.

Environment Conditions :

• Operating Temp. : 0–50°C

• Humidity : 5–90% (non-condensing)

Warranty : 12 Months (from date of installation)
